Immersion Heater Not Working – Find Out Why and What to Do

An immersion heater is an electric device that heats water in a tank or cylinder by using a heating element that is immersed in the water. it powered by electricity and have their own thermostat to control the temperature of the water. Immersion heaters are a convenient and energy-efficient way to provide hot water for domestic or industrial purposes. However, sometimes they may stop working due to various reasons. In this blog post, we will discuss some of the common causes of immersion heater failure and how to troubleshoot them.

Causes of Immersion Heater Failure

There are several factors that can cause an immersion heater to stop working properly. Some of the most common ones are:

  • Faulty thermostat: The thermostat is the device that regulates the temperature of the water in the tank or cylinder. If the thermostat is defective, it may not sense the correct temperature and either overheat or underheat the water. This can result in scalding or freezing water, or no hot water at all. A faulty thermostat can also cause the immersion heater to run continuously and waste electricity.
  • Faulty heating element: The heating element is the part of the immersion heater that converts electricity into heat. It is usually made of metal and has a coil or loop shape. If the heating element is damaged, corroded, or burnt out, it may not heat the water effectively or at all. A faulty heating element can also cause the immersion heater to trip the circuit breaker or blow a fuse.
  • Faulty wiring or connections: The wiring and connections of the immersion heater are the parts that deliver electricity from the power supply to the heating element and the thermostat. If the wiring or connections are loose, frayed, or broken, they may cause a short circuit or a fire hazard. They may also prevent the immersion heater from receiving enough power or any power at all.
  • Sediment build-up: Sediment is the accumulation of minerals, dirt, or rust that can form inside the tank or cylinder over time. Sediment can reduce the efficiency and lifespan of the immersion heater by insulating the heating element and preventing heat transfer. Sediment can also clog the pipes and valves and affect the water pressure and flow.
  • Faulty timer or switch: The timer or switch is the device that controls when the heater is turned on or off. If the timer or switch is malfunctioning, it may not activate or deactivate the immersion heater as intended. This can result in the immersion heater running unnecessarily or not running at all.

How to Troubleshoot Immersion Heater Problems

If your immersion heater is not working properly, you can try some of the following steps to identify and fix the problem:

  • Check the power supply: Make sure that the immersion heater is plugged in and switched on. Check the circuit breaker or fuse box and see if there is any tripped or blown fuse. If there is, reset or replace it and try the immersion heater again. If the problem persists, there may be a fault in the wiring or connections of the immersion heater.
  • Check the thermostat: Test the thermostat by turning it up or down and see if the water temperature changes accordingly. You can also use a multimeter to measure the resistance of the thermostat and see if it matches the manufacturer's specifications.
  • Check the heating element: Test the heating element by touching it carefully and see if it feels hot or cold. If the heating element is cold, it may not be receiving power or it may be burnt out. You can also use a multimeter to measure the resistance of the heating element and see if it matches the manufacturer's specifications. If the resistance is too high or too low, the heating element is defective and needs to be replaced.
  • Check the sediment build-up: Drain the tank or cylinder and inspect the inside for any signs of sediment. If there is a lot of sediment, you may need to flush the tank or cylinder with a descaling solution or vinegar to dissolve and remove the sediment. You may also need to replace the anode rod, which is a metal rod that prevents corrosion inside the tank or cylinder. If the anode rod is worn out or missing, it may cause the heating element to corrode faster and fail sooner.
  • Check the timer or switch: Test the timer or switch by turning it on or off and see if the immersion heater responds accordingly. If the timer or switch is not working properly, it may need to be adjusted, repaired, or replaced.

When to Call a Professional

If you are not confident or experienced in handling electrical or plumbing issues, you should always call a professional to fix your immersion heater problems. Attempting to repair the heater yourself may cause more damage or injury. You should also call a professional if the problem is beyond your ability or knowledge to fix, such as a major wiring or connection fault, a leaking or cracked tank or cylinder, or a complex timer or switch malfunction. A professional can diagnose and repair the problem safely and efficiently, and also provide you with advice on how to maintain and optimize your immersion heater performance.


Heater is a useful device that can provide you with hot water whenever you need it. However, like any other appliance, it can sometimes malfunction due to various reasons. By following the steps above, you can troubleshoot some of the common immersion heater problems and fix them yourself or with the help of a professional. By doing so, you can restore your immersion heater function and enjoy hot water again. For more information on heaters and other heating products, you can visit the website of Beeco Electronics , a leading manufacturer and exporter of industrial heaters, packing machines, and thermocouples. Beeco Electronics offers a wide range of high-quality and reliable immersion heaters, as well as other types of heaters, sensors, and controllers. You can also contact them for any queries or orders.
