This is Temperature Controller , Single Display Basic Feature and the Model no is TC-19.  7 Segment LED Display (4/3 Digit) , Fixed input TC/RTD , PID /ON-OFF   , Auto /Self tuning
Heating (Relay || SSR)  , Economical PID range.

Model Name/Number TC-19
Pannel Cutout(mm) 92×92
Input Sensor J/K/R/S/PY-100 2Wire or 3Wire (Factory Set)
Range j (0°C to 400°C or 0°C to 600°C)
K (0°C to 1200°C)
PT-100 2wire or 3wire (0°C to 400°C, -50.0°C to 200.0°C)
Output 1 Relay 1C/O 5A, 230V AC resistive load) & SSR (Factory Set)
Control Action TP / ON-OFF (Configurable)
Accuracy ±1% of FSD
Supply  230V AC±10%, 50HZ
Dimension(HxWxD)  96x96x42


Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
