Multispan TC-49 , Temperature Controller , Single Display Basic Feature

1,073.00


Warning: Undefined array key "enable_rtb_widget" in /var/www/html/wp-content/plugins/woo-razorpay/woo-razorpay.php on line 2947

Description

This is Temperature Controller , Single Display Basic Feature and the Model no is TC-49.  7 Segment LED Display (4/3 Digit) , Fixed input TC/RTD , PID /ON-OFF   , Auto /Self tuning
Heating (Relay || SSR)  , Economical PID range.



Model Name/Number TC-49
Pannel Cutout(mm) 45×45
Input Sensor J/K (Configurable) or
PT-100 2 wire or 3 wire(Factory set)
Range  j (0°C to 600°C )
K (0°C to 999°C)
PT-100 (-50.0°C to 200.0°C)
Output 1 Relay 1C/O 5A, 230V AC resistive load) & SSR Drive O/P 12V DC,
Control Action TP / ON-OFF (Configurable)
Accuracy ±1% of FSD
Supply 100-270V AC (SMPS),50/60 Hz
Dimension(HxWxD) 48x48x70



Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
