This is Packaging Controller  and the Model no is MC-1003. For mechanical & semi-pneumatic machine type  . 4+4 Digit , 7 segment LED
NPN/PNP Proxy , Micro-switch . One set point , 1 relay . Alarm mode


Model Name/Number MC-1003
Pannel Cutout(mm) 92×92
Input NPN Proxy for clutch
NPN Color mask sesnor (CMS)
Micro switch
Range Clutch on time :- 0-99.99 sec.
0-99.99 sec.
Output  for clutch
for inching
for batch counter
Reset front Reset
Memory Non-Volatile Memory
Supply 100-270V AC(SMPS),50/60Hz
Dimension(HxWxD)  96x96x52



Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
