Flexys Rail (FL-RL-DI.4-PS-24V-CE-RoHS)

1,325.00

Flexys Rail (FL-RL-DI.4-PS-24V-CE-RoHS) offers a concise control solution with notable features. Its display consists of 12 LEDs indicating card and communication status for a selectable slot, along with a 7-segment display showing slot numbers. Compact at 140 x 93.6mm, it efficiently utilizes space.

It comes with 4 Digital Inputs on the Power Supply Card, with further input options via Flexys Card selection. Supporting 4 slots for expansion, it evolves alongside your needs. The unit includes an RTC with Time Switch Function, ample 351KB Code Memory, and communication interfaces including RS485-based MODBUS RTU Protocol and a proprietary protocol. Compatible with a range of supply voltages, it’s designed for Din Rail mounting. It accommodates both digital and analog I/O, with a maximum counting frequency of 5KHz on power supply cards and 30Hz for normal digital inputs.

Category:

Description

Display Type 12 LEDs To Indicate Card And Communication Status For Selectable Slot, One 7 Segment To Display Slot No.
Size 140 x 93.6mm
Digital Inputs 4 Digtal Inputs On Power Supply Card + As Per Flexys Card Selection
Analog Inputs As Per Flexys Card Selection
Digital Outputs As Per Flexys Card Selection
Analog Outputs As Per Flexys Card Selection
No. of Slots 4
RTC With Time Switch Function Available
Code Memory 351KB
Communication Interface RS485 Based MODBUS RTU Protocol, Proprietary Protocol
Expansion Yes
Supply Voltage 100 to 230 VAC / 18 to 24 VDC
Mounting Type Din Rail
FI / Maximum Counting Frequency FC0 (I0 & I1) & FC1 (I2 & I3) – 5KHz (on power supply card only), Normal digital inputs – 30Hz

Additional information

Weight 1 kg
