HTC206 is a versatile Humidity and Temperature Controller designed to accurately regulate environmental conditions. With its 7 Segment LED Dual Display featuring a 4+4 digit configuration, it provides clear and precise readings. The controller accepts 5V RH (HS-A-100) sensor inputs for humidity and RTD (PT100) sensor inputs for temperature, offering a resolution of 0.1 for humidity and RTD inputs. Its remarkable accuracy includes ±1º of full-scale accuracy for humidity and 0.1% of full-scale accuracy for RTD.
Equipped with dual set points and relay outputs, the HTC206 allows for efficient control. The humidity control utilizes ON-OFF settings while temperature control offers both ON-OFF and PID options. The controller incorporates load protection protocol, Low/High alarms, and even includes a complimentary RH sensor. Operating with a supply voltage of 90-270V AC/DC, the compact 72 x 72mm size and panel mount design make installation seamless. The HTC206 ensures precision and reliability for maintaining optimal humidity and temperature conditions in various applications.
- Additional information
|7 Segment LED Dual Display
|Type of Inputs
|5V RH (HS-A-100) sensor for Humidity,
RTD(PT100) sensor for Temperature
|0.1 / 1 for RH / RTD inputs
|Humidity : ±1º of full scale,RTD: 0.1% of full scale
|Type of Output
|For Humidity: ON-OFF
For Temperature:ON-OFF / PID control
|Load protection protocol, Low / High Alarm, Free RH sensor with unit
|72 x 72mm
