Multispan MS-1208A Temperature Scanner 8 channel
₹3,525.00
- Description
- Additional information
Description
This is Temperature Scanner 8 Channel 1 and Model no is MS-1208A. MS 1208A has 8 analog inputs . 8 Channel – Universal input , Scroll/Hold facility , Up to 4 Relay RS-485 MODBUS Communication (on request).
| Model Name/Number | MS-1208A |
| Pannel Cutout | 92X92 |
| Input | 0-10V DC/4-20mA DC/ 0-20mA DC (Configurable) |
| Range | (-999 TO 9999) |
| Output | RS-485 Modbus Communication (Optional) |
| Control Action | PID/ On-Off (Configurable) |
| Accuracy | ±1% of FSD |
| Supply | 100-270V AC, 50/60 HZ |
| Dimension | 96X96x52 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
| Weight | 1 kg |
|---|
