Multispan PC-444 Programmable Counter
₹1,609.00
- Description
- Additional information
Description
This is Programmable Counter and the model no is PC-444. 6+4 Digit , 7 segment LED . NPN/PNP Proxy , Micro-switch, Encoder Pulse input . Auto/Manual reset
Up to 2 set point , 2 relay . Counting direction Up/Down . Memory retention . Diameter setting parameter
| Model Name/Number | PC-444 |
| Pannel Cutout(mm) | 45×45 |
| Input | NPN/PNP Proximity switch/ Micro switch (Configurable)230VAC Pulse/ Encoder(Factory set) |
| Range | 0-9999/0-999.9 count |
| Output | 1relay 1C/O 5A , 230V AC(Resistive load) |
| Reset | Auto reset/Manual reset / reset at back |
| Memory | yes/no (Configurable) |
| MPM Range | 999.9MPM |
| Diameter | 0-9999.99mm |
| Supply | 230V AC ±10%,50Hz |
| Dimension(HxWxD) | 48x48x70 |
Usually dispatched within 4 working days
Warranty : 1 year cover { not valid if found fire burnt or damaged }
Additional information
| Weight | 1 kg |
|---|
