This is PID Controller – 3 output and the Model no is UTC-4203.   4 + 4 Digit , 7 Segment LED Display . Universal input TC/RTD  . PID/ON-OFF  . Auto /Self tuning
3 Programmable output (Relay or SSR)


Model Name/Number UTC-4203
Pannel Cutout(mm) 45×45
Input Sensor J/K/PT-100 2W/3W (Configurable)
Range j (0°C to 600°C),K (0°C to 1200°C)
PT-100 2W/3W(-99°C to 400°C, -99.9°C to 400.0°C)
Output 3 Relay 1C/O, 5A,230V AC(Resistance load) or SSR Drive O/P 12V DC, (3 Set Point)
Supply  100 to 270V AC  , 50/60HZ
Accuracy ±1% of FSD
Control Action PID / ON-OFF
Dimension(HxWxD) 48x48x95


Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
