Multispan , UTR-4244 , Digital Timers Dual output

2,063.00

Category:

Warning: Undefined array key "enable_rtb_widget" in /var/www/html/wp-content/plugins/woo-razorpay/woo-razorpay.php on line 2947

Description

This is Digital Timers Dual output ,  and the Model no is UTR-4244  .   Dual 7 Segment LED Display   Four Programmable mode –
1) FWD /REV 2) CYCLIC 3) COMBINATIONAL 4) Sequenctial
Timer range – Sec/Min/Hours
2 output (Relay or SSR)

Model Name/Number UTR-4244
Pannel Cutout(mm) 45×45
Input Star Pulse Micro Switch/Limit Switch/Proximity (Configurable)
Range 9999/999.9/99.99Sec/Min/Hrs (Configurable)
Output  2 Relay 2C/O 5A,230V AC (Resisitve load) or SSR Drive O/P 12V DC Output (Any onr Factory set)
Programm Forward – Reverse Mode/Cyclic Mode/Sequential Mode/Combination Mode(Configurable)
Control Direction Up/Down (Configurable)
Memory  Yes/No (Configurable)
Supply 100-270V AC (SMPS),50/60 Hz
Reset Front&Backl Both Reset Avaible
Dimension(HxWxD) 48x48x70





Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
