Pallet cling film wrapper . CL-101

107,800.00

CL-101 Pallet Cling Film Wrapper, a versatile and efficient solution for your packaging needs. Designed and produced by BEECO, an Indian brand, this semi-automatic machine offers a range of features to enhance your packaging efficiency.

Machine Specifications:

  • The CL-101 Pallet Cling Film Wrapper has a flexible size range, with dimensions of L:100-900 mm x W:100-900 mm x H:100-900 mm.
  • It is made of MS (mild steel) material and has a total product weight of 200 kg.
  • The machine is powered by a 120 W electric motor operating at 220V single-phase voltage.
  • The turntable speed is adjustable at 30 r/min, providing flexibility for different packaging needs.
  • The machine features a PLC control system for precise and customizable wrapping.
  • The turntable diameter is 600 mm, and the machine’s dimensions are L:1150 mm x W:600 mm x H:1860 mm.

Features:

  • The machine includes a top pressing feature to ensure secure and stable packaging.
  • It can efficiently wrap a variety of products, including apparel, beverages, chemicals, commodities, and food items.
  • The CL-101 comes with a 1-year warranty, covering manufacturing defects.

Additional Information:

  • The machine can handle loads up to 60 kg and has a load weight capacity of 80 kg.
  • Its wrapping efficiency is around 20-40 loads per hour.
  • The stretch film roll width can be up to 18 inches.
  • The machine can handle stretch film thickness ranging from 15-35um.
  • Warranty coverage is limited to a 100 km radius from the city of Chandigarh.

Shipping and Freight:

  • Freight charges will be additional and on a to-pay basis.
  • The machine will be shipped in a wooden box up to the transport location in Chandigarh on a to-pay basis.

The CL-101 Pallet Cling Film Wrapper by BEECO offers a comprehensive solution for efficient and secure packaging. With its features, warranty, and versatility, it’s designed to meet various packaging needs and enhance your operational efficiency.


Warning: Undefined array key "enable_rtb_widget" in /var/www/html/wp-content/plugins/woo-razorpay/woo-razorpay.php on line 2947

Description

Paper Size 100-900 mm
Material MS
Automation Grade Semi-Automatic
Packaging Type Belt, Film
Driven Type Electric
Power 120 W
Voltage 220V
Phase SINGLE
Size/Dimension L:100-900 mm x W:100-900mm x H:100-900 mm
Capacity 760 mm*760 mm * 760 mm
Model Name/Number CL-101
Product Weight 200kg
Conveying Speed 30 r/min rotary speed, adjustable
Control System PLC program
Machine Weight 200
Packaging Size L:100-900 mm x W:100-900mm x H:100-900 mm
Product Type BOX Wrapping Machine
Warranty 1 YEAR
Turntable Speed 30 r/min
Rotating Platform Speed 30 r/min rotary speed, adjustable
Max Pallet Height H:760*760 mm
Turn Table Diameter L:100-900 mm x W:100-900mm x H:100-900 mm
Dimensions Of The Machine L:1150 mm x W:600mm x H:1860 mm
Height H:1860 mm
Stretching Type WRAPPING
Load Weight Capacity 80kgs
Maximum Load Diameter 900*900*900 mm
Packaging Efficiency 50-80 times/h
Stretch Film Thickness stretch film 100-900 mm,15-35um
Turntable Height H:100-900 mm
Width W:100-900mm
Wrap Height H:100-900 mm
Usage/Application APPAREL, Beverage, Chemical, Commodity, Food, Ma
Brand BEECO  { INDIAN}
Carton Size (L x W x H) L:100-900 mm x W:100-900mm x H:100-900 mm
Film roll inner dia 100-900 mm
Machine Size L:1150 mm x W:600mm x H:1860 mm
Max Load Size L:100-900 mm x W:100-900mm x H:100-900 mm
Max Load Size(mm) L:100-900 mm x W:100-900mm x H:100-900 mm
Throat Gap (Turntable Center To Film Roll Center) 750 mm
Box Size 760*760*760 mm
Speed 0-30 RPM
Turntable Motor 0.37 kW
Stretch Film Roll Width 18 Inch Max
Max Packing 60 kg
Net Weight 160 kgs
Turntable Diameter 600 mm
Wrapping Efficiency 20-40 loads per hour

FEATURES : WITH TOP PRESSING

FREIGHT CHARGES : WILL BE EXTRA ON TO PAY BASIS , WE WILL SHIP IN WOODEN BOX TILL TRANSPORT IN CHANDIGARH ON TO PAY BASIS

WARRANTY : 1 YEAR COVER , UNDER 100 KM RADIOUS FROM CITY CHANDIGARH ONLY .
