Selec MFM284-C-CE
₹3,840.00
MFM284-C-CE presents an LCD with backlight, offering a display configuration of 3 rows with 4 digits each, and an additional row of 8 digits. With diverse electrical connections including 3-phase 3-wire, 3-phase 4-wire, 2-phase 3-wire, and 1-phase 2-wire, it includes a pulse output. Featuring a compact size, it provides %THD analysis up to the 31st level, Max/Min Demand (Power), Max Demand Current, and Phase Sequence Detection. Employing RS485 and MODBUS RTU communication protocols, it supports CT Primary ranging from 1 / 5A to 10kA and CT Secondary at 1 / 5A (Programmable). The meter allows programmable PT Primary and PT Secondary within 100V to 500kV and 100V to 500V ranges respectively. It operates with a rated input voltage of nominal 5A AC (Min – 11mA Max – 6A) and a supply voltage range of 85 to 270V AC (45/65 Hz). With a size of 72 x 72mm, it’s designed for panel mounting and is certified with CE RoHS.
- Description
- Additional information
Description
| Display Type | LCD with Backlight |
| Display Configuration | 3 Rows of 4 Digits, 1 Row of 8 Digits |
| Electrical Connection | 3Ø – 3W, 3Ø – 4W, 2Ø – 3W, 1Ø – 2W |
| Type of Output | Pulse Output |
| Features | Compact Size, %THD upto 31st Level, Max/Min Demand (Power), Max Demand Current, Phase Sequence Detection |
| Communication Protocol | RS485 and MODBUS RTU |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5A ( Programmable ) |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100V to 500V (Programmable for Any Value) |
| Rated Input Voltage | Nominal 5A AC (Min – 11mA Max – 6A) |
| Supply Voltage | 85 to 270V AC (45/65 Hz) |
| Size | 72 x 72mm |
| Mounting Type | Panel Mount |
| Certification | CE RoHS |
Additional information
| Weight | 1 kg |
|---|
