MFM384-C-CE

3,840.00

MFM384-C-CE features an LCD with backlight, complete with a bargraph representation for current. It showcases a display configuration consisting of 4 rows with 4 digits each and an additional row of 8 digits. Offering versatile electrical connections including 3-phase 3-wire, 3-phase 4-wire, 2-phase 3-wire, and 1-phase 2-wire, the meter incorporates a pulse output. Noteworthy features encompass %THD analysis up to the 31st level, Max/Min Demand (Power), Max Demand Current, and Phase Sequence Detection. Supporting RS485 and MODBUS RTU communication protocols, it accommodates programmable CT Primary within 1 / 5A to 10kA and CT Secondary at 1 / 5A. It also allows programmable PT Primary and PT Secondary spanning 100V to 500kV and 100V to 500V ranges respectively. Rated for a nominal 5A AC input current (Min – 11mA Max – 6A), the supply voltage range extends from 85 to 300V AC (45/65Hz). With dimensions of 96 x 96mm, it is designed for panel mounting and holds certifications for CE RoHS, UL, and MID


Warning: Undefined array key "enable_rtb_widget" in /var/www/html/wp-content/plugins/woo-razorpay/woo-razorpay.php on line 2947

Description

Display Type LCD with Backlight, Bargraph Representation for Current
Display Configuration 4 Rows of 4 Digits, 1 Row of 8 Digits
Electrical Connection 3Ø – 3W, 3Ø – 4W, 2Ø – 3W, 1Ø – 2W
Type of Output Pulse Output
Features %THD upto 31st Level, Max/Min Demand (Power), Max Demand Current, Phase Sequence Detection
Communication Protocol RS485 and MODBUS RTU
CT Primary 1 / 5A to 10kA (Programmable for Any Value)
CT Secondary 1 / 5A ( Programmable )
PT Primary 100V to 500kV (Programmable for Any Value)
PT Secondary 100V to 500V (Programmable for Any Value)
Rated Input Current Nominal 5A AC (Min – 11mA Max – 6A)
Supply Voltage 85 to 300V AC (45/65Hz)
Size 96 x 96mm
Mounting Type Panel Mount
Certification CE RoHS, UL & MID

Additional information

Weight 0.5 kg
