MFM384-R-C-CE

3,840.00

MFM384-R-C-CE is equipped with an LCD display featuring backlighting and configured as 1 row of 4 digits and 2 rows of 7 digits. It supports electrical connections including 3-phase 3-wire, 3-phase 4-wire, 2-phase 3-wire, and 1-phase 2-wire configurations. Offering phase angle detection and energy measurements (Active, Reactive, Apparent), it also tracks import/export energy and min/max demand power. Communication happens through RS485 and MODBUS RTU protocols. It accommodates CT Primary ranging from 1/5A to 10kA, and CT Secondary at 1/5A. PT Primary can be set from 100V to 500kV, while PT Secondary ranges from 100V to 500V. It operates on a supply voltage of 85 to 270V AC (47/63 Hz), mounts on Din Rail, and holds CE RoHS & MID certifications


Warning: Undefined array key "enable_rtb_widget" in /var/www/html/wp-content/plugins/woo-razorpay/woo-razorpay.php on line 2947

Description

Display Type LCD with Backlight
Display Configuration 1 Row of 4 Digits, 2 Rows of 7 Digits
Electrical Connection 3Ø – 3W, 3Ø – 4W, 2Ø – 3W, 1Ø – 2W
Features Phase Angle Detection, Energy (Active / Reactive / Apparent), Import / Export Energy, Min / Max Demand Power
Communication Protocol RS485 and MODBUS RTU
CT Primary 1 / 5A to 10kA (Programmable for Any Value)
CT Secondary 1 / 5 A (Programmable)
PT Primary 100V to 500kV (Programmable for Any Value)
PT Secondary 100V to 500V (Programmable for Any Value)
Supply Voltage 85 to 270V AC (47/63 Hz)
Size 70mm
Mounting Type Din Rail Mount
Certification CE RoHS & MID

Additional information

Weight 0.5 kg
