Selec MiBRX IO Cards (MiBRX-SC-DI06)


MiBRX IO Cards (MiBRX-SC-DI06), a versatile solution tailored to your diverse input and output needs.

With 6 Digital Inputs of PNP Type, it efficiently interfaces with various sensors and devices.

For Analog Inputs, it offers a spectrum of options:

  • 4 Universal Input channels (TC, RTD, 0-10V, 0-20mA)
  • 4 TC, RTD channels
  • 6 channels for 0-10V and 0-20mA
  • 4 channels for Load Cell inputs

In the realm of Digital Outputs, choose from 3 or 4 options, including Relay and Transistor configurations. Output ratings range from 5A @230VAC / 24VDC for Relay to Source Type 100mA @24V DC or 1A @24V DC for Transistor.

The Analog Outputs encompass 1 channel for 0-10V and 0-20mA, ensuring accurate signal transmission.

Seeking versatility? The Combination Card offers options like 2 Digital Inputs-2 Digital Outputs and 2 Digital Inputs-1 Analog Input, ensuring adaptable functionality.

For specialized needs, explore the realm of Special Function Cards, including Datalogging, RTC (Real-Time Clock), WiFi, and Loadcell interfacing.

In summary, the MiBRX IO Cards provide an extensive array of input and output capabilities, catering to diverse requirements with precision and flexibility.



Digital Inputs 6  PNP Type
Analog Inputs 4 Channel – Universal Input (TC, RTD, 0-10V, 0-20mA) , 4 Channel – TC, RTD , 6 Channels – 0-10V, 0-20mA , 4 Channel – Load Cell
Digital Outputs 3/4 – Relay, Transistor, Transistor
Output Rating 5A @230VAC / 24VDC (Relay) , Source Type 100mA @24V DC (Transistor) / 1A @24V DC (Transistor)
Analog Outputs 1 Channel – 0-10V, 0-20mA
Combination Card 2 Digital Inputs-2 Digital Outputs ,2 Digital Inputs-1 Analog Input
Special Function Cards Datalogging, RTC, WiFi, Loadcell

Additional information

Weight 1 kg
