Description

This is Batch Counter and the Model no is LC-445 .6+4 Digit , 7 segment LED . NPN/PNP Proxy , Micro-switch, Encoder Pulse input . Auto/Manual reset  . Up to 2 set point , 2 relay Counting direction Up/Down . Memory retention . Diameter setting parameter . RS-485 MODBUS optional



Model Name/Number LC-445
Pannel Cutout(mm) 45×45
Input NPN/PNP Proximity switch (Configurable) Encoder(Factory set)
Range 0-99999.9/0-999999/0-9999.99/0-999.999 Meter (configurable)
Output  1relay 1C/O 5A@230V AC(Resistive load)
Reset Auto reset/Manual reset facility & front and back reset
Memory Non-Volatile Memory
MPM Range 999.9MPM
Diameter 0-9999.99mm
Supply 100-270V AC/DC(SMPS),50/60 Hz
Dimension(HxWxD) 48x48x95





Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
