This is Humidity Controller  and the Model no is MHC-1101 .  Rh sensor ( uptil 85% Rh ) provided. 4 Digit single or Dual 7 Segment LED Display  . Humidity and temperature RTD input
Individual relay output for humidity and temperature

Model Name/Number MHC-1101 (Humidity Controller)
Pannel Cutout(mm) 92×92
Input Sensor Humidity Sensor
Range  0.0 to 100.0%
Output 1 Relay 1C/0 5A @ 230V AC (Resistive Load)
Supply  100 to 270V AC (SMPS) , 50/60HZ
Accuracy ±1% of FSD
Control Action PID / ON-OFF
Dimension(HxWxD) 96x96x52


Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
