SP112-GT70-S1-CE

9,280.00

SP112-GT70-S1-CE showcases a 7″ LCD Screen with 65536 colors and 800 x 480 Pixels resolution, excluding Ethernet. User memory consists of 128MB Flash or 262MB Flash with 64MB DRAM. It operates on 24 VDC power and has inbuilt data logging, storing up to 100,000 logs. Featuring a 7″ Resistive Touch Screen, it measures 203 x 149mm. The device supports communication through Serial ports COM1 (RS485) and COM2 (RS232/RS485), Ethernet via ETH PORT (10M/100M Self Adaptation), and USB via USB Port (USB 2.0). Equipped with Real-Time Clock, data logging, recipes, alarms, and password protection, it maintains performance between 0°C and 50°C while offering IP65 protection.

Category:

Description

Display Type 7″ LCD Screen (65536 colors) without Ethernet
Resolution 800 x 480 Pixels
User Memory 128MB Flash /262MB Flash+ 64MB DRAM
Supply Voltage 24 VDC
Data logging Inbuilt ( Upto 100000 logs )
Display Configuration 7″ Resistive Touch Screen
Size 203 x 149mm
Communication Serial : COM1 (RS485), COM2 (RS232 /RS485)
Ethernet : ETH PORT(10M / 100M Self Adaptation)
USB : USB Port (USB 2:0)
Real Time Clock (RTC) Yes
Data Logging Yes
Recipes Yes
Alarms Yes
Password Yes
Ingress Protection IP65
Working Temperature 0°C to 50°C

Additional information

Weight 1 kg
