VFD-L-1-010-230V

6,723.00

VFD-L-1-010-230V demonstrates versatile performance with a single-phase AC input voltage range of 230 VAC ±15% and a power of 1HP/0.75KW. It operates on frequencies of 50Hz/60Hz using Space Vector PWM-based Scalar Control. Offering a frequency control range of 0.1~400 Hz, it allows smooth operation. The acceleration and deceleration time settings, ranging from 0 to 999.9 seconds, provide precise control. Notably, it has robust overload capabilities, handling 150% for 1 minute, 180% for 10 seconds, and 200% for 1 second. The VFD includes protection functions against over current, over/under voltage, over temperature, overload, under current, and system errors. Rated IP20, it can operate between -10°C to +55°C under <90% humidity and indoor conditions below 1000m altitude.

Category:

Warning: Undefined array key "enable_rtb_widget" in /var/www/html/wp-content/plugins/woo-razorpay/woo-razorpay.php on line 2947

Description

AC Input Voltage Range Single Phase: 230 VAC ±15 % , 1HP/0.75KW
Frequency Range 50Hz/60Hz
Control Mode Space Vector PWM Based Scalar Control
Frequency Control Range 0.1~400 Hz
Acc./Dec. Time 0-999.9 sec., 4 acceleration and deceleration time setting available
Overload Capacity 150% for 1min, 180% for 10sec, 200% for 1sec.
Protection functions Over current, Over voltage, Under voltage, Over Temperature, Overload, Under current, System error
Ingress Protection IP20
Working Temperature -10°C ~ +55°C , Humidity : <90%, No condensation, IP20, Indoor, <1000m altitude above sea level



Additional information

Weight 0.5 kg
