Description

This is Economy PID Controller 1 output  and the Model no is UTC-114.  4 Digit , 7 Segment LED Display . Universal input TC/RTD . PID/ON-OFF  . Auto /Self tuning  .  Heating /Cooling (Relay&SSR)

Model Name/Number UTC-114
Pannel Cutout(mm) 92×92
Input Sensor J/K/PT-100 2W/3W (Configurable)
Range j (0°C to 400°C),K (0°C to 600°C) PT-100 2Wire or 3Wire
(-99°C to 400°C) K (0°C to 1200.0°C)
Output 1 Relay 1C/O, 5A,230V AC(Resistance load) or SSR Drive O/P 12V DC, 30mA (Parallel relay) (1 Set Point)
Supply  100 to 270V AC , 50/60HZ
Accuracy ±1% of FSD
Control Action PID / ON-OFF (Configurable)
Dimension(HxWxD)  96x96x52



Usually dispatched within 4 working days

Warranty : 1 year cover { not valid if found fire burnt or damaged }

Additional information

Weight 1 kg
