Select XTC5400
₹2,561.00
XTC5400 display employs LED technology and offers a 4 + 4 Digits display configuration. It includes 2 C/O SPST relay contacts and a wide range of timing options: 99.99 / 999.9 / 9999sec, 99.59 min:sec, 999.9 / 9999min, 99:59 hr:min, 999.9 / 9999hr. Counter mode ranges from -999 to 9999 Counts. Operating modes include Timer: ON Delay / Interval / Cyclic (ON first) / Cyclic (Off first) / Batch, and Counter: ON Delay / Interval / Auto Reset, Time Pulse Repeat, Batch. The display features Memory Retention and Batch Counting functions. It supports sensor types NPN, PNP, and Potential Free Contacts, with supply voltages of 90 to 270V AC/DC and 24V AC/DC. Sized at 48 x 48mm, it’s designed for panel mounting and holds both CE and UL certifications.
- Description
- Additional information
Description
| Display Type | LED |
| Display Configuration | 4 + 4 Digits |
| Relay Contact | 2 C/O SPST |
| Range | 99.99 / 999.9 / 9999sec, 99.59 min:sec, 999.9 / 9999min, 99:59 hr:min,999.9 / 9999hr Counter:-999 to 9999 Counts |
| Operating Modes | Timer: ON Delay / Interval / Cyclic (ON first) / Cyclic (Off first) / Batch Counter:ON Delay / Interval / Auto Reset,Time Pulse Repeat , Batch |
| Reset | Front, Remote, Power Interruption |
| Counting Direction | Timer: Down, Counter: Up / Down |
| Features | Memory Retention, Batch Counting |
| Sensor type | NPN, PNP, Potential Free Contacts |
| Supply Voltage | 90 to 270V AC / DC, 24V AC/DC |
| Size | 48 x 48mm |
| Mounting Type | Panel Mount |
| Certification | CE & UL |
Additional information
| Weight | 1 kg |
|---|
