Selec XT5042


The XT5042 is a sophisticated and versatile timing relay that offers extensive features for precise timing control across various applications.

The XT5042 timing relay offers an impressive array of features for various timing scenarios. Its dual 7-segment LED display ensures clear visibility of both set values and elapsed time, enhancing monitoring accuracy.

The presence of 2 C/O SPST output contacts enables the relay to control two different electrical circuits, making it suitable for applications that require synchronized switching.

With memory retention, multiple operating modes, and reset options, the XT5042 ensures ease of use and convenience in diverse scenarios. Its compatibility with different supply voltages and industry certifications further enhance its versatility and reliability.

In summary, the XT5042 timing relay is a comprehensive solution for applications demanding advanced timing control, versatility, and safety. Its compact design, mounting options, and certifications make it an excellent choice for automation and control panels that require precision and reliability.



Display Type 7 Segment LED, Dual Display
Display Configuration 4 + 4 Digits
Output Contact 2 C/O SPST
Feature Memory Retention
Range 99.99 / 999.9 / 9999sec, 99.59min:sec / 999.9 / 9999min, 99.59hr:min / 999.9hr / 9999hr
Operating Modes Interval, ON Delay, Cyclic ON first, Cyclic OFF First, Forward – Pause – Reverse, Instantaneous + Delayed Batch
Reset Front, Remote, Power Interruption
Counting Direction Up / Down
Supply Voltage 85 to 270V AC , 24V AC / DC
Size 48 x 48mm
Mounting Type Panel Mount
Certification CE, UL

Additional information

Weight 1 kg
